Ultimate Door and Window Security with Advanced Wireless Technology
AJAX BASELINE DoorProtect is a state-of-the-art wireless magnetic opening detector designed to provide early warning of potential intrusions through doors or windows. With its high-end technology and user-friendly features, DoorProtect ensures your property is always secure.
Key Features
- Advanced Detection Technology: Uses premium British-made reed switches to detect the opening of doors or windows by monitoring changes in the magnetic field.
- Versatile Installation: Compatible with all door types, including metal doors, and includes magnets of various sizes for easy installation on narrow frames and door frames.
- Long Battery Life: Operates for up to 7 years on a single CR123A battery, requiring no frequent replacements.
- Reliable Performance: Delivers alarm signals in just 0.15 seconds, with a communication range of up to 1,200 meters in open spaces.
- Sophisticated Security: Features include authentication to prevent forgery, jamming detection, communication channel encryption, and tamper resistance.
- External Contact Support: Connects third-party sensors for enhanced security options.
- Temperature Sensor: Monitors temperature with an operating range from -10°C to +40°C.
Principle of Operation
DoorProtect functions by detecting the magnetic field disruption caused by the opening of a door or window. It can also be used in transmitter mode to send signals from a wired sensor to the hub. The device is composed of two modules—a detector and a magnet—with two different-sized magnets for flexible installation:
- Large Magnet: Effective up to 2 cm from the detector.
- Small Magnet: Effective up to 1 cm from the detector.
Installation and Setup
- Ready to Use: Comes with a pre-installed CR123A battery and requires no disassembly.
- Easy Connection: Connects to the hub with just one click through the mobile app.
- Quick Mounting: Install on the SmartBracket in just a few minutes.
Technical Specifications
- Type: Wireless Magnetic Opening Detector
- Sensing Element: Reed Switch
- Alarm Signal Delivery: 0.15 seconds
-
Activation Threshold:
- Small Magnet — 1 cm
- Large Magnet — 2 cm
- Power Supply: CR123A Battery, 3V
- Battery Life: Up to 7 years
-
Radio Technology: Jeweller
- Communication Range: Up to 1,200 m in open space
- Operating Frequencies: 868.0-868.6 MHz
- RF Output Power: Up to 20 mW
- Encryption: AES Algorithm
- Detector Polling Period: 12−300 s
- Temperature Range: -10°C to +40°C
- Humidity: Up to 75%
- Dimensions: Diameter 20 mm, Height 90 mm
- Weight: 29 g
What's Included
- DoorProtect Opening Detector
- SmartBracket Mounting Panel
- Two Magnets (Large and Small)
- CR123A Battery (Pre-installed)
- External Contact
- Installation Set
- User’s Guide
